Danh mục sản phẩm: | |||||
Memosens COS81D | Liquiline CM442R | Liquiline Compact CM82 | |||
| Measurement range: - 0.004 to 30 mg/l - 0.05 to 330% SAT - 0.1 to 700 hPa Process temperature: 0 to 140°C Process pressure: 0.02 to 13 bar abs |
| Design: 2x Memosens input, 2 to 4x current output Ingress protection: - Transmitter: IP20 - Optional display: IP66 |
| - Input: One channel transmitter - Output / communication: 4 to 20 mA, HART - Ingress protection: IP67, IP68, NEMA type 6 |
|
Memosens COS51E | Oxymax COS61D | Cleanfit CPA871 | |||
| Measurement range: - 0.01 to 100 mg/l - 0 to 1000% SAT - 0 to 2000 hPa Process temperature: -5 to 60°C Process pressure: Max. 5 bar abs |
| Measurement range: - 0 to 20 mg/l - 0 to 200% SAT - 0 to 400 hPa Process temperature: -5 to 60°C Process pressure: Max. 10 bar abs |
| Stainless steel, Alloy C22 PEEK: 16 bar up to 140°C Process temperature: -10°C to 140°C for all materials (- PVDF, conductive PVDF) -10 to 100 / 90°C for PVDF, conductive PVDF |
|
Cleanfit CPA875 | Memobase Plus CYZ71D | 1-/2-channel transmitter bundle with 4-wire field meter | |||
| Process temperature: -10 to 140°C Process pressure: - Pneumatic drive: 16 bar up to 140°C - Manual drive: 8 bar up to 140°C |
| - Measuring principle: Potentionmetric - Product consists of PC software, USB cable, sensor connection box MemoLink and Memosens lab cable CYK20 optionally, CYK10 with M12 plug can be used alternatively |
| - Characteristic: Liquiline CM72 - Measurement range: pH sensor: 0 to 14pH |
|
Oxymax COS22D | Oxymax COS51D | Zero-point gel COY8 | |||
| Measurement range: - 0.001 to 20 mg/l - 0 to 200% SAT - 0 to 400 hPa Process temperature: -5 to 135°C Process pressure: 1 to 12 bar abs |
| Measurement range: - 0.01 to 100 mg/l - 0 to 1000% SAT - 0 to 2000 hPa Process temperature: -5 to 50°C Process pressure: Max. 10 bar |
| - Measuring principle: Amperometric oxygen measurement - Measurement range: Zero point - Dimension: Available for 12mm and 40mm oxygen sensors |
|
