Data sheet
| Power loss [W] for rated value of the current – at AC in hot operating state – at AC in hot operating state per pole – without load current share typical | 185.7 W 61.9 W 10 W |
| Insulation voltage – of main circuit with degree of pollution 3 rated value – of auxiliary circuit with degree of pollution 3 rated value | 1000 V 500 V |
| Ambient temperature – during operation – during storage | -25…+60°C -55…+80°C |
| Operational current – at AC-1 – at AC-3 | 650 - 690 A 170 A |
| Control supply voltage at AC | 220...240 V |
| Control supply voltage at DC rated value | 220...240 V |
